50cbm bulk haul feed semitrailer for sale
the specification of bulk feed trailer
Overall dimension(L*W*H) of bulk feed trailer : 12000×2550×3950（mm）(approximate)
28T single-action outriggers, 90# tractor pin, 12R22.5 12PR tires, steel spring suspension, 3 axles.
A, Bulk feed container material: 5mm thickness aluminum alloy ellipse shape, 8mm thickness secondary beam,feed inlet dimension: 900X900.
B, Volume: 50cubic meters.-55cubic meters.
C, compartments: 5 compartments
D, discharging way: hydraulic system discharging, multi-way valve, DENISON hydraulic pump, EATON motor, 75KW diesel engine, radiation installed, 220Liters volume hydraulic oil tanker, 200Liters volume diesel tanker.
E, length of auger: 8m length
F, paint color: white color, the company logo free to paint.
G, retrofitting: pneumatic switch box for feed outlet.
The bulk haul feed semitrailer adopts high quality thickness aluminum alloy ellipse shape tanker welded, 8mm thickness secondary beam, 50cubic meters volume. There are 5 independent compartments for bulk feed trailer .
Working principle of Bulk feed trailer for sale ： hydraulic system discharging, hydraulically controlled the feeding auger lifting up-down or flatting and rotating ±180°. Easy discharging. The bulk feed container color: white color; the auger color: blue color. Color is request.
Main technical parameters of bulk haul feed semitrailer
Item | Unit | Parameters | ||
Product name |
| Round shape Bulk feed trailer for sale | ||
Truck model |
| CLW9401ZSL | ||
Saddles max loading weight (kg) |
| 16000 | ||
Overall parameters | Total mass | kkg | 40000 | |
Rated mass | 29960 | |||
Curb mass | 9980 | |||
Overall dimension(L*W*H) | mmm | 13000X2550X3980 | ||
Wheelbase(mm) | 7120+1310+1310 | |||
Approach/departure angle | ° | -/12 | ||
Tire specification | 12R22.5*12+1 | |||
Volume | M3 | 62 | ||
Bulk haul feed semitrailer in mainly used to transport bulk feed or raw grain for feed production from feed factories to livestock farms, poultry farms and feed processing users. At the same time, it can be used to transport some non corrosive power and granular raw materials, such as pharmaceutical powder and grain depot turnover.
Advantages of bulk feed trailer : simple structure, reliable performance, large conveying capacity, convenient operation, string mobility and no pollution to materials, etc.
Application of bulk haul feed semitrailer : transportation of feed for large, medium and small breeding enterprises.
bulk haul feed semitrailer
Bulk feed trailer for sale
bulk feed trailer
Bulk feed trailer for sale
Key words: Bulk feed trailer for sale, bulk haul feed semitrailer, bulk feed trailer , bulk feed semitrailer, bulk feed trailer manufacturer, bulk feed truck, bulk feed semitrailer, bulk feed semitrailers, feed trailers, etc.
· **Lightweight Tank with Large Feed Capacity for Bulk feed trailer for sale :** The tank is designed to be lightweight, allowing for a larger feed load capacity up to 60 cubic meters, optimizing transportation efficiency.
· **International Brand Hydraulic Components of bulk haul feed semitrailer :** Features durable components from global brands, including hydraulic pumps and motors, ensuring long service life and reliability.
· **Configurable Compartments of bulk feed trailer :** The bulker can be divided into 6-8 compartments, each capable of carrying different types of feed formulas, enhancing the versatility of feed transport.
· **Customizable Unloading Auger of bulk feed trailer :** The length of the unloading auger can be tailored to specific needs, providing stable and reliable operation with high unloading capacity.
Welcome to our FAQ section, where we aim to address your most pressing questions about our bulk haul feed semitrailer. At CHENGLI, we understand the importance of making informed decisions, especially when it involves the efficiency and reliability of your feed transportation operations. Below, you’ll find answers to common inquiries regarding our products, services, and the unique advantages we offer. Should you have any further questions or require detailed information, please don’t hesitate to contact us directly. Our team is here to provide you with the support and insights you need to ensure seamless feed handling and transportation.
Our bulk feed trailer boast an impressive unloading speed, thanks to the 273mm diameter vertical auger, significantly larger than the standard 219mm. This design enhancement ensures that a 13-meter semi-trailer can be unloaded in just 25-30 minutes, maximizing efficiency in your operations.
We've indicatively designed our augers to minimize feed breakage. Our vertical auger, with an enlarged pipe diameter and reduced rotational speed, paired with double-helix blades, significantly lowers the crushing rate. With CLW, feed breakage is reduced to just 40% of the industry average, ensuring optimal feed utilization.
Absolutely! We offer customization options, including painting the bulk haul feed semitrailer with your company logo or any design you prefer. At CLW, we make sure your bulker not only performs well but also aligns with your brand identity.
Understanding the importance of ease of use, we provide detailed instructional videos for each operation step. In many countries, our local partners and service teams offer hands-on assistance. Additionally, for initial usage, we can dispatch an engineer to ensure smooth operation.
We maintain a well-stocked spare parts inventory in China for rapid dispatch. Additionally, in several countries, we have local stores for even faster access, ensuring minimal downtime for your operations.
Quality is our priority. That's why we use internationally renowned brands like Schneider for our electrical components, ensuring longevity and reliability in every CLW product.
thanks to our expansive production warehouse, we ensure swift manufacturing processes. Most of our bulkers can be prepared and ready for delivery within 30-40 days, ensuring you receive your quality product promptly.
Customer satisfaction is our priority. We offer comprehensive after-sales support including access to our expert team for maintenance advice, spare parts, and any operational assistance you might require throughout the lifespan of your bulk haul feed semitrailer.
We are a leading manufacturer of special trucks, tankers, trailers, and spare parts in China Welcome to visit us in Suizhou city, the production base of Chinese special purpose vehicles
T/T 30-50% as deposit, and the rest before delivery. We'll show you the photos of the products and packages before you pay the balance
EXW, FOB, CFR, CIF, DAF, DDU
Generally, it will take 20 to 30 days after receiving your advance payment. The specific deliver time depends on the items and the quantity of your order
Yes. We have professional R&D team, we can produce the product exactly according to your requirements
We are direct sales from the factory, so the price is very competitive. Different products have different prices. The price also depends on your special needs. To know the exact price, please contact us
Yes, we have 100% test before delivery
We provide lifelong tracking service and one year free warranty for all of our products. Meanwhile we provide free training and technical support to guide you repair your product. lf you need, we will also supply original spare parts and you just need to pay the freight
