Box volume: 5.8 (m ³)
Battery manufacturer: CATL
Cell type: Lithium iron phosphate
Range: 295 (km)
Rated power: 53.58 kWh
Rated voltage: 334.88 (V)
Energy density: 145.59 (Wh/kg)
Maximum speed: 90 km/h
Control mode: manual/automatic
Loading operation cycle time: 15 (s)
Filling operation cycle time: 25 (s)
Unloading cycle time: 45 (s)
Approach angle/departure angle: 18/14 (°)
Tire model: 185R15LT 8PR
[Other configurations]
On the basis of SAIC Yuejin's pure electric Class II chassis, a dedicated garbage disposal and transportation vehicle is equipped with a garbage bin, garbage filler, and hydraulic system, which integrates mechanical, hydraulic (pneumatic), and electrical components. Narrow body+single row+left side, hydraulic front plate and rear drum, central locking+remote key, power battery protection, reinforced leaf spring ABS+EBD、 Equipped with rear shock absorber, self-adjusting clearance, cruise control, high-voltage power interface, DC fast charging, upper temperature monitoring (shared cooling), creeping, ramp assisted start stop, etc.
Chassis advantages
1. Adopting Ningde Times 53.58kWh third-generation brand new battery (with a warranty of eight years and 400000 kilometers)
2. The longest range in the same class can reach 295km, with lower energy consumption and higher operational efficiency,
3. The discharge depth is greater, reaching up to 90% of the total battery capacity (second-generation batteries will be limited to 80% torque)
4. Compared to the 55.7kWh battery, the available power of the 55.7kWh battery is 44.5kWh, and the available power of the SAIC Yuejin 53kWh battery is 51kWh, with an additional 6.5 kWh available.
5. The best lightweight in the same class, with a chassis curb weight of 1580kg, which is about 300kg lighter than vehicles in the same class. The whole vehicle is not overweight and does not require disassembly of equipment and optional parts for registration.
6. The 100kw permanent magnet synchronous motor independently developed by SAIC Maxus has strong power, and the VCU and BMS control system jointly developed by SAIC and Bosch has better and more advanced control logic.
7. The protection level is IP68, which is better than all 55.7kwh products on the market!
8. The chassis configuration is rich, with standard features such as hill assist, cruise control, multiple driving modes, central locking with electric shake, Bluetooth+radio+USB, fog lights+daytime running lights, and many other rich configurations!
[Performance and Features]
1. The permanent magnet synchronous motor directly takes power, specially matched for each vehicle, perfectly matched without a power take-off, saving more steps and reducing the failure rate compared to diesel vehicles.
2. The oil pump adopts the well-known domestic brand Hepres liquid oil pump, equipped with a compaction valve to increase compression density and increase loading capacity. The loading capacity is equivalent to two and a half times that of non compressed waste of the same tonnage.
3. The oil tank is enlarged and the volume is increased to prevent high temperature of hydraulic oil. All hydraulic oil must be added to the oil tank through a hydraulic oil filter to filter impurities in the hydraulic oil, reduce the failure rate, and effectively prevent damage to accessories. The multi way valve adopts a Sino foreign joint venture brand, and is matched with the Hepres multi way valve and Hepres oil cylinder, with a low failure rate and CAN bus control mode; Less wiring, low failure rate, automatic display of fault codes, convenient for maintenance and repair.
4. Homework automation: Adopting a dual system control of photoelectric switch and time, with one button unloading and wireless remote control device, all filling and unloading operations only need to be operated by one driver. It can set two operation modes: fully automatic and semi-automatic, which not only reduces the labor intensity of sanitation workers, but also greatly improves the working environment.
5. The homework system has dual functions of computer control and manual operation, greatly ensuring and improving the utilization rate of vehicles.
6. Flip mechanism: An optional flip mechanism with a garbage bin (or bucket) can be installed.
