Weichai 160 horsepower, Wanliyang 6-speed transmission, clutch assist, spring braking, leather seats, color screen instrument panel, electronic control air horn, multifunctional steering wheel (including cruise control), anti splash system, reflective vest, National VI emission monitoring terminal, enhanced rear lower protection, adjustable front headlights, air dryer, front and rear axle wear alarm device, lightweight front lower protection, triangular warning sign, parking wedge, universal special chassis, automatic brake clearance adjustment device, central locking and electric doors and windows, widened frame style rearview mirror (four mirror type), enhanced dynamic rotation, 11/9+7TH, electrically adjustable air conditioning, exhaust braking, tires: 8.25R16 18PR, 120L aluminum alloy fuel tank.
Platform rotation: 180 °
Curved arm rotation: ± 100 (insulated crank arm) improves operational flexibility and enhances phase to phase operational safety
Arm frame form: one folding arm+two telescopic arms (can be equipped with small crutches and insulated hooks)
Rotating device: Continuous 360 ° infinite rotation
Support legs; Front and rear H-shaped legs, adjustable separately
Operating system: two sets of operating systems for the work platform and the vehicle
Control System: Electro hydraulic Proportional Control System
Leveling system: master-slave hydraulic leveling system
Automatic interlocking device for boarding and alighting: used for interlocking boarding and alighting to prevent the risk of tipping over due to misoperation
Oil cylinder anti retraction device: a safety protection device that prevents the oil cylinder from retracting and the working arm from falling when the hydraulic pipeline fails
Leg anti retraction device: When the system suddenly loses pressure, lock the leg cylinder to prevent the vehicle from tipping over
Emergency electric hydraulic pump: When the chassis engine or hydraulic main pump fails, it provides emergency power to send the staff back to the ground (with emergency stop function)
Among special - purpose vehicle companies, the company has passed ISO9001 - 2008 quality management system certification, ISO14001 environmental management certification, OHSAS18001 occupational health and safety management system certification, 3C mandatory certification, automotive energy - saving and environmental - protection certification, new - energy vehicle certification, export product quality license certification, product quality certification, and EU CE certification, etc. It has obtained special production license qualifications such as A2, C2, C3 pressure vessels, truck - mounted cranes, vehicle - mounted cranes, fire trucks, and national equipment scientific research and production qualifications. The company has more than 200 independently innovative products that have obtained national patents.
The company offers over 6,000 varieties of vehicles, including sprinkler trucks, garbage trucks, sewage suction trucks, night - soil suction trucks, oil tank trucks, chemical trucks, wreckers, aerial work platforms, fire trucks, truck - mounted cranes, refrigerated trucks, van trucks, pressure vessels, road maintenance vehicles, flatbed transporters, bulk grain trucks, dry - mixed mortar trucks, beekeeper trucks, stage trucks, propaganda trucks, mobile vending trucks, heavy - duty truck - mounted cranes, concrete pump trucks, pharmaceutical transport vehicles, and food transport vehicles, etc. Its products are exported to more than 100 countries and regions in the Middle East, Africa, Southeast Asia, South America, etc. The company's output value has consistently ranked among the top in various provinces and cities across the country. Its exports cover more than 30 countries and regions such as North Korea, New South Wales, and Angola, and the market share of its leading products exceeds 20%.
Q1.You are a factory or trading Company?
Yes, we are the overseas sales department of the factory. And welcome to visit our factory.
Q2 . Could your company modify the standard product depending on my request?
Yes. Our company is specialized in researching and designing various special-purpose vehicles and spare parts. We can provide
any product according to your demand.
Q3. Could your company totally customize products for me?
We can provide the customized-designing product meeting with any of your demands.
Q4. Could you provide the certification that we need?
We can provide various certifications associated with the truck.
Q5. How long could we receive our goods?
It depends on the product that you have ordered. If the goods are prepared, we will deliver your goods as soon as possible.
Send your message to this supplier
We are a leading manufacturer of special trucks, tankers, trailers, and spare parts in China Welcome to visit us in Suizhou city, the production base of Chinese special purpose vehicles
T/T 30-50% as deposit, and the rest before delivery. We'll show you the photos of the products and packages before you pay the balance
EXW, FOB, CFR, CIF, DAF, DDU
Generally, it will take 20 to 30 days after receiving your advance payment. The specific deliver time depends on the items and the quantity of your order
Yes. We have professional R&D team, we can produce the product exactly according to your requirements
We are direct sales from the factory, so the price is very competitive. Different products have different prices. The price also depends on your special needs. To know the exact price, please contact us
Yes, we have 100% test before delivery
We provide lifelong tracking service and one year free warranty for all of our products. Meanwhile we provide free training and technical support to guide you repair your product. lf you need, we will also supply original spare parts and you just need to pay the freight
